"Road kill" P-38 by DJ Aerotech

29 Dec 01 - New page added.

Roadkill - front starboard quarter
N° of launches / Time 0 0 mins



Wingspan 27¾ "  m
Wing Area 100 in² 6.5 dm²
Flying Weight est. 4.1 oz est. 115 g

stated with 7 cell 50mAh pack

Wing Loading est. 5.9 oz/ft². est. 18.0 g/dm²
Wing Cube Loading 7.1 - Trainer (almost)
Motor 2 x N20 motors, supplied in the kit
Gearbox 2 x self-assembly gearboxes 4.2:1, supplied with motor
Propeller 2 x Günther 125mm x 110mm (4.9" x 4.3")
Batteries 7 NiCd cells Sanyo N-50AAA or 8 NiMH 170mAh cells recommended
Speed Controller probably a GWS ICS-50FP - 4 to 8 cells - 2A - BEC
Receiver probably a Jeti REX 5 plus - 5ch - sub-micro - 35MHz
Servos Elevator - Hitec HS-50
Ailerons, Rudder & Nosewheel - Hitec HS-50 (1 servo does all 3 controls)
Static motor parameters

Not tested

Flight Performance Not yet flown

29 Dec 01 - New indoor scale kit just arrived from the USA. It comes complete with all hardware, motors and propellers.
